Description
-
Model No.: DZP060BG24
-
Input: 346~415V, 3 x 60A
-
Output: 200~240VAC
-
Outlets: 24 ports of C39 sockets with self-locking feature, compatible with C13 and C19
-
Output phase rotation ABCABC in black, red, blue
-
Protection: each TWO ports have 1P 20A UL489 hydraulic magnetic circuit breaker
-
Remote monitor PDU input and each port current voltage, power, KWH
-
Smart meter with Ethernet/RS485 interface, support HTTP/SNMP/SSH2/MODBUS
-
Onboard LCD display with menu control and local monitoring
-
Ambient temperature up to 60°C
-
Input cable 5*6AWG, 3 meters
Additional Information
| Dimensions |
1828*65*82 mm |
|---|---|
| Model No. |
DZP060BG24 |
